Temperature-controlled Colorimetric Lab Drums is especially suitable for comparison tests for various processes in tanning & leather chemical industries.
Brand:
AVENOItem NO.:
AF57Payment:
T/T, L/CShipping Port:
Xiamen portLead Time:
3-7daysApplication
Temperature-controlled Colorimetric Lab Drums is especially suitable for comparison tests for various processes in tanning & leather chemical industries.
Temperature-controlled Colorimetric Lab Drums consists of two drums, which are in same sizes so that several tests can be conducted simultaneously. The drum body consists of two layers and between them (interlayer) there is heating medium (water or anti-freeze fluid) which is circulated. This equipment is equipped with heating and temperature control device and its speed can be regulated steplessly with a frequency converter. The total operation time as well as automatic forward & backward rotation time, and the interval between the forward and backward operations can be set up. A water feeding device is provided to feed water or material during operation of the drum. A convenient clutch system can stop any one of the drums during operation at will. The observation window is made of fully transparent high-strength toughened glass so that the test conditions of the leather inside the drum can be observed all time.
Feature
Fully transparent toughened glass observation window.
Feeding device can be fed with water while the drum is in operation.
Dimension & Weight
Model |
AF57 Temperature-controlled Colorimetric Lab Drums |
|
AF57-1 |
AF57-2 |
|
Dimensions |
90*140*150cm |
90*245*150cm |
Key Specification
Model |
AF57 Temperature-controlled Colorimetric Lab Drums |
|
AF57-1 |
AF57-2 |
|
Drum quantity |
2 |
4 |
Volume |
2*10L |
4*10L |
Drum diameter |
370mm |
|
Drum width |
200 |
|
Speed |
0-25rpm |
|
Heating method |
Electronic heating |
|
Power supply |
AC220V, 50/60HZ |
