AG17B Hydrostatic Head Tester

Hydrostatic Head Tester is used to measure the impermeability of various fabrics that have undergone water-repellent treatment.

  • Brand:

    AVENO
  • Item NO.:

    AG17B
  • Payment:

    T/T, L/C
  • Product Origin:

    China
  • Shipping Port:

    Xiamen port
  • Lead Time:

    3-7days
  • Product Detail

Application

Hydrostatic Head Tester is used to measure the impermeability of various fabrics that have undergone water-repellent treatment, such as canvas, tarpaulin, tent cloth, rainproof clothing cloth and geotextile materials.


Feature of Hydrostatic Head Tester

1. Servo motor drive system, the microcomputer controls the water flow, the pressure rate range is wide and can be steplessly adjustable, and the pressurization speed is accurate.

2. Pneumatic clamping sample makes the sample is evenly stressed and prevent damage to the sample.

3. Five test modes are optional: pressurization method, constant pressure timing method, constant pressure constant timing method, disturbance relaxation and water leakage method.

4. Built-in automatic rating function.

5. Built-in wireless wifi, wireless control of the instrument through the tablet. Built-in portable printer. It can be connected to a computer and automatically draw real-time test data curves for easy observation.


Standards

GB/T 4744, AATCC 127, ISO 811, BS EN 20811, BS 3321, 3424-26, JIS L 1092A/B, FZ/T 01004.


Dimensions & Weight

Model

AG17B Hydrostatic Head Tester

Dimensions

55x 43x63cm

Weight

60kg


Key Specification

Model

AG17B-1

AG17B-2

AG17B-3

Test range

200KPa

500KPa

1000KPa

Testing method

Pressurization method

Constant pressure timing method

Constant pressure constant timing method

Disturbance relaxation

Water leakage method

Pressure display resolution

1 / 10000

Sensor test accuracy

1% (5%-100% within single sensor full scale range)

Experimental area

100cm² 7.8cm² (optional)

Pressurization rate

0.1KPa ~ 10KPa / min (infinitely adjustable)

Display mode

Color touch screen

Power supply

AC 220V, 50/60Hz

Standard Accessories

Model

AG17B Hydrostatic Head Tester

100cm² griper

1set

Calibration plate

1set

Rubber ring

2pcs

English operate software

1set

Cable connect with PC

1pc

Power line

1pc
