The Slip Resistance Test Equipment is mainly used to evaluate the shoes slip resistance property and test the friction between the sole, front of the sole and heel of the finished shoes and the ground when walking.
Brand:
AVENOItem NO.:
AF09Payment:
T/T, L/CShipping Port:
Xiamen portLead Time：
3-7daysApplication
The Slip Resistance Test Equipment is mainly used to evaluate the shoes slip resistance property and test the friction between the sole, front of the sole and heel of the finished shoes and the ground when walking.
Standards
EN 13287, SATRA TM144, GB/T 28287, ASTM F2913, ISO 20344, ISO 20345
Dimension & Weight
|
Model |
Slip Resistance Test Equipment |
|
Dimensions |
170*60*115cm |
|
Weight |
300kg |
Key Specification
|
Model |
Slip Resistance Test Equipment |
|
Control mode |
Computer control |
|
Sensor |
Vertical load cell: 100kg*1 |
|
|
Horizontal load cell: 100kg*2 |
|
Standard vertical pressure |
500±25N (for footwear of European size 40, UK size 6.5 and above) 400±20N (for footwear below European size 40, UK size 6.5) |
|
Slip speed range |
100 mm/s～500 mm/s, can be set |
|
Standard slip speed |
300 mm/s±3 mm/s |
|
Wedge Angle gauge |
EN standard 7°, SATRA 5° |
|
Test floor |
Compressed tile floor, stainless steel board, carpet |
|
Power supply |
AC220V, 50/60HZ |
