UV Accelerated Weathering Tester is suitable for the performance reliability test of various industrial products. The equipment uses ultraviolet light as the luminescent source and the ultraviolet radiation aging test of the material by simulating the ultraviolet spectrum of natural solar light.
Brand:
AVENOItem NO.:
AG19Payment:
T/T, L/CProduct Origin:
ChinaShipping Port:
Xiamen portLead Time：
3-7daysApplication
UV Accelerated Weathering Tester is suitable for the performance reliability test of various industrial products. The equipment uses ultraviolet light as the luminescent source and the ultraviolet radiation aging test of the material by simulating the ultraviolet spectrum of natural solar light.
Dimension & Weight
|
Model |
AG19 UV Accelerated Weathering Tester |
|
Dimension |
58*128*135cm |
|
Weight |
150KG |
Key Specification
|
Model |
AG19 UV Accelerated Weathering Tester |
|
Control model |
Touch screen control |
|
Test chamber dimension |
60×50×750cm |
|
Temperature range |
RT+10~70°C |
|
Humidity range |
≥90%RH |
|
Temperature uniformity |
±1°C |
|
Temperature fluctuation |
±0.5°C |
|
Temperature control |
PID SSR control |
|
Distance from sample to lamp |
50±2mm (adjustable) |
|
Centre distance between the lamp |
70mm |
|
Irradiance |
1.0W/cm²(adjustable) |
|
Effective irradiation areas |
45×117×50cm |
|
Testing time |
0~999H, adjustable |
|
Lamp |
40W/pc, 8pc (UVA/UVB, life time above 1600h) |
|
Ultraviolet wavelength |
UVA340: 315-400nm UVB313: 280-315nm |
|
Standard specimen size |
75×285mm |
|
Blackboard temperature |
40℃～65℃ |
|
Power Supply |
AC220V, 50/60HZ |
Standard Accessories
|
Model |
AG19 UV Accelerated Weathering Tester |
|
Sample fixture |
1set |
|
UVA Lamp |
1set |
|
English manual operate video |
1set |
