TEXTILE TEST EQUIPMENT

AG30 45Degree Automatic Flammability Tester

45 Degree Automatic Flammability Tester is suitable for testing the performance of textiles that are in the hands of consumers or taken from consumers, except for children's pajamas or protective clothing.

  • Brand:

    AVENO
  • Item NO.:

    AG30
  • Payment:

    T/T, L/C
  • Product Origin:

    China
  • Shipping Port:

    Xiamen port
  • Lead Time:

    3-7days
  • Product Detail

Application

45 Degree Automatic Flammability Tester is suitable for testing the performance of textiles that are in the hands of consumers or taken from consumers, except for children's pajamas or protective clothing. 45 Degree Automatic Flammability Tester is used to test the flammability of textiles used in clothing, introduces three types of flammability, determines the requirements for textile classification, and applies the use of single-layer or multi-layer fabrics that are commercially unsuitable for clothing and have the possibility of burning. caveat.


Standards

 ASTM D1230, AATCC 33-1962, FTMS191-5908, 16 CFR 1610, CALIF TB117, JIS L1091.


Dimension & Weight


Model

AG30 45Degree Automatic Flammability Tester

Dimension

48*49*56 cm

Weight

27kg


Key Specification


Model

AG30 45Degree Automatic Flammability Tester

Test chamber size

37*22*35cm, with 12 vent hole φ12.7mm

Sample shelf

45°

Sample clip

Slot on the board 38*152mm

Distance of fire nozzle axis and rotation axis

44mm

Distance of fire nozzle and sample surface

8mm

Distance of fire nozzle and mark line

127mm

Sample dimension

50*150mm

Power

AC 220V, 50/60HZ


Standard Accessories


Model

AG30 45Degree Automatic Flammability Tester

Sample fixture

1pc

Spring clamp

10pcs

Brushing device

1set

Flame scale gauge

1pc

Cotton thread

1pc

Gas feed device

1set

Power line

1pc
